G215HAN01.3

EMAIL

ITEMS

SPECIFICATIONS

Screen Diagonal

21.5”

Active Area

476.064 (H) x 267.786 (V)

Pixels H x V

1920(x3) x 1080

Pixel Pitch

247.95 (per one triad) ×247.95

Pixel Arrangement

R.G.B. Vertical Stripe

Display Mode

AHVA Mode, Normally Black

White Luminance ( Center )

250 cd/m2 (Typ.)

Contrast Ratio

1000 (Typ.)

Optical Response Time

22

Nominal Input Voltage VDD

5 V (Typ)

Power Consumption

(VDD line + LED line)

11.1W (Typ.)

LCD module : PDD (Typ.)= 2.3 @ White

pattern,Fv=60Hz

Backlight unit : PBLU (Typ.) =8.8W

Weight

1740 (Typ)

Physical Size

497.6(H) x 292.2(V) x 10.5 (D)Typ

Electrical Interface

Dual LVDS

Support Color

16.7M colors

Surface Treatment

Anti-Glare, 3H

RoHS Compliance

RoHS Compliance

Temperature Range Operating Storage (Shipping)

0~ 60-20~ 60
